| Printing |
Printing Method |
Direct thermal/Thermal transfer |
| Resolution |
203 DPI / 300 DPI |
| Max. Printing Speed |
8 ips(203 DPI) / 6 ips(300 DPI) |
| Max. Printing Width |
108 mm(203 DPI) / 106 mm(300 DPI) |
| Max. Printing Length |
2286 mm(203 DPI) / 1524 mm(300 DPI) |
| CPU |
|
32-bit RISC CPU |
| Memory |
RAM |
128MB |
| Flash |
256MB |
| Detection |
Sensor |
Out-of-paper detection, gap detection, ribbon detection, black mark |
| detection, cover-opening detection |
| Media |
Types |
Black mark label, punched hole label, folding or rolling die cutting label |
|
| Width |
1” (25.4mm) ‒ 4.33” (110mm) |
| Height |
0.31” (8mm)‒ 9.84” (250mm) |
| Thickness |
0.002”(60um)-0.08”(200um) |
| Label Roll Diameter |
5”(127 mm) Max |
| Core Diameter |
0.5”(12.7 mm), 1”(25.4 mm). 1.5”(38 mm) |
| Ribbon |
Type |
Wax, Wax/Resin, Resin |
| Width |
2” (50mm) ‒ 4.38” (118mm) |
| Length |
984.2′ (300 m) |
| Core Diameter |
1”(25.4 mm) |
| Programming Language |
|
ZPL, TSPL,EPL,DPL |
| Software |
Label Design Software |
HPRT BarTender Ultralite (professional and higher versions are |
| available for trial) |
| Driver |
Seagull Windows Vista7,8,10, Vista, 7, 8, 11 |
| Resident Fonts |
Bitmap fonts |
6, 8, 12, 16, 32, OCR A & B. 90°, 180°, 270° rotatable and 10 magnification. |
| TTF fonts |
CG Triumvirate™times expandable in horizontal and vertical |
| directions, simplified Chinese. |
| Code Pages |
|
DOS437,720,737,755,775,850,852,855,856,857,858,860,862,863,864,865,866, |
| Windows 1250,1251,1252,1253,1254,1255,1256,1257,1258, |
| ISO8859-1,-2,-3,-4,-5,-6,-8,-9,-15 |
| Barcodes |
1D |
Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave |
| 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on |
| MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11 |
| 2D |
PDF417, Maxicode, DataMatrix, QR Code, Aztec, CODE49, CODABLOCK,PDF417, |
| Maxicode, DataMatrix, QR Code, Aztec |
| Interfaces |
Standard |
USB, Serial, Ethernet |
USB, Serial, Ethernet, USB HOST |
| Optional |
Wi-Fi or Bluetooth |
Wi-Fi or Bluetooth |
| Control Panel |
|
Two-color status light: power indicator, status indicator |
|
Four control buttons: power button, pause button, feed button, cancel button |
| Power Supply |
|
Power Switch |
| Input: AC 100-240 V, 50/60 Hz |
| Output: DC 24 V / 2.5 A |
| Environment |
Operation |
41℉(5℃) to 104℉(40℃) , humidity 30% to 85% ,non-condensing |
| Storage |
-4℉(-20℃) to 122℉(50℃), humidity 10% to 90% ,non-condensing |
Physical
Characteristic |
Dimension(L*H*W) |
308×250×180mm |
| Weight |
2.8 KG |
| User Interface |
Five LED lights, four buttons |
3.5” Touch Screen, four buttons |
| Options & Accessory |
|
Peeler module, cutter module, external label roll holder |
| Agency Approval |
|
CE,FCC,RoHS |
